Product details
| Connectivity | |
| Total Connectors | 1 x 24-Pin ATX Motherboard |
| 2 x 4 4-Pin EPS CPU | |
| 6 x 6 2-Pin PCIe | |
| 12 x 6-Pin SATA / Peripheral | |
| 4 x 4-Pin Peripheral / Molex | |
| 1 x 4-Pin Floppy | |
| Cable Design | Modular |
| Electrical | |
| Total Wattage | 1000 W |
| Number of 12 V Rails | 1 |
| Max Load for 12 V | 83.3 A |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 13 A |
| General | |
| Efficiency Rating | 80 PLUS Platinum |
| Active Power Factor Correction | 0% |
| Efficiency | 92% at 50% Load |
| Cooling | |
| Fan Size | 120 mm |
| Fan Speed | 2150 rpm |
| Bearing Type | Ball |
| Fan Life Expectancy | 120,000 Hours |
| Physical | |
| Form Factor | ATX |
| Compliance | ATX 12 V v2.52 |
| Protection | No Load Operation, Over-Current Protection, Over-Power Protection, Over-Temperature Protection, Over-Voltage Protection, Short-Circuit Protection, Surge and Inrush Protection, Under-Voltage Protection |
| Certifications | BSMI, CB, CE, cTUVus, EAC, FCC, NOM, TUV, , |
| *as per Manufacturer | |
| Dimensions | 5.9 x 3.4 x 6.3″ / 150 x 86 x 160 mm |
| Packaging Info | |
| Package Weight | 8.97 lb |
| Box Dimensions (LxWxH) | 13.2 x 8.3 x 6.3″ |
