Product details
| Print Head / Ink | |
| Type | Permanent (Replaceable) |
| Number of Nozzles | Total 1 792 nozzles |
| Ink Bottles | GI-70 (Pigment Black / Cyan / Magenta / Yellow) |
| Printing Resolution | 4 800 (horizontal)*1 x 1 200 (vertical) dpi |
| Print Speed*2 Based on ISO/IEC 24734 Click here for Summary Report Click here for Document Print and Copy Speed Measurement Conditions | |
| Document (ESAT/Simplex) | 13.0 images per minute (black) / 6.8 images per minute (colour) |
| Document (ESAT/Duplex) | 2.9 images per minute (black) / 2.8 images per minute (colour) |
| Document (FPOT Ready/Simplex) | 9s (black) / 14s (colour) |
| Photo (10.16 x 15.24cm) (PP-201/Borderless) | 37s |
| Printable Width | 203.2mm (20.32cm) Borderless: 216mm (21.59cm) |
| Printable Area | |
| Borderless Printing*3 | Top/Bottom/Right/Left margin: each 0 mm |
| Bordered Printing | #10 Envelope/DL Envelope: Top 8 mm / Bottom 12.7 mm / Right 5.6 mm / Left 5.6 mm127x127 mm: Top 6 mm / Bottom 6 mm / Right 6 mm / Left 6 mm 89×89 mm / 10.16 x 10.16cm: Top 5 mm / Bottom 5 mm / Right 5 mm / Left 5 mm LTR / LGL: Top 3 mm / Bottom 5 mm / Right 6.3 mm / Left 6.4 mm Other: Top 3 mm / Bottom 5 mm / Right 3.4 mm / Left 3.4 mm |
| Bordered Auto 2-Sided Printing | Top / Bottom margin: 5 mm Left / Right margin: 3.4 mm (l: Left: 6.4 mm, Right: 6.3 mm) |
| Support Media | |
| Rear Tray | Plain Paper (64-105 g/m² (gsm)) Photo Paper Pro Platinum (PT-101) Photo Paper Pro Luster (LU-101) Photo Paper Plus Glossy II (PP-201/PP-208) Matte Photo Paper (MP-101) Glossy Photo Paper “Everyday Use” (GP-508) High Resolution Paper (HR-101N) Photo Paper Plus Semi-Gloss (SG-201) Photo Stickers (PS-108/PS-208/PS-808) Removable Photo Stickers (PS-308R) Magnetic Photo Paper (PS-508) Envelope |
| Cassette | Plain Paper (64-105 g/m² (gsm)) |
| Paper Size | |
| Rear Tray | A4, A5, B5, LTR, LGL, 10.16 x 15.24cm, 12.7 x 17.78cm, 17.78 x 25.4cm, 20.32 x 25.4cm, Envelopes (DL, COM10), Square (12.7 x 12.7cm, 10.16 x 10.16cm, 89×89 mm), Card Size (91×55 mm)[Custom size] width 55 – 215.9 mm, length 89 – 676 mm |
| Cassette | A4, A5, B5, LTR [Custom size] width 148.0 – 215.9 mm, length 210 – 297 mm |
| Paper Size (Borderless)*4 | A4, l, 10.16 x 15.24cm, 12.7 x 17.78cm, 17.78 x 25.4cm, 20.32 x 25.4cm, Square (12.7 x 12.7cm, 10.16 x 10.16cm, 89×89 mm),Card Size (91×55 mm) |
| Paper Handling ( Number) | |
| Rear Tray | Plain Paper (A4, 64 g/m² (gsm)) = 100 High Resolution Paper (HR-101N) = 80 Photo Paper: 10.16 x 15.24cm = 20 |
| Cassette | Plain Paper (A4, 64 g/m² (gsm)) = 250 |
| Support Media for Auto 2-sided printing | |
| Type | Plain Paper |
| Size | A4, A5, B5, l |
| Paper Weight | |
| Rear Tray | Plain Paper: 64-105g/m² (gsm) Canon paper: Maximum paper weight: 300 g/m² (gsm) (Photo Paper Pro Platinum PT-101) |
| Cassette | Plain Paper: 64-105g/m² (gsm) |
| Ink End Sensor | Electrode type and dot count type combined |
| Print Head Alignment | Auto/Manual |
Scan
| Scanner Type | Flatbed |
| Scanner Method | CIS (Contact Image Sensor) |
| Optical Resolution*6 | 1 200 x 2 400dpi |
| Scanning Bit Depth (Input/Output) | |
| Grayscale | 16bit/8bit |
| Colour | RGB each 16bit/8bit |
| Line Scanning Speed*7 | |
| Grayscale | 1.5 ms/line (300dpi) |
| Colour | 3.5 ms/line (300dpi) |
| Flatbed | A4/l (216 x 297 mm) |
Copy
| Document Size | |
| Flatbed | A4/l |
| Compatible Media | |
| Size | A4/A5/B5/l/LGL/10.16 x 15.24cm/12.7 x 17.78cm/Card Size (91 x 55 mm) |
| Type | Plain Paper Photo Paper Pro Platinum (PT-101) Photo Paper Pro Luster (LU-101) Photo Paper Plus Semi-Gloss (SG-201) Glossy Photo Paper “Everyday Use” (GP-508) Matte Photo Paper (MP-101) Photo Paper Plus Glossy II (PP-201) Photo Paper Plus Glossy II (PP-208) |
| Image Quality | 3 positions (Economy, Standard, High) |
| Density Adjustment | 9 positions, Auto intensity (AE copy) |
| Copy Speed*8 Based on ISO/IEC 24734 Click here for Summary Report Click here for Document Print and Copy Speed Measurement Conditions | |
| Document Colour (sFCOT/Simplex) / (sESAT/Simplex) | 20s / 5.1s |
| Multiple Copy | |
| Black/Colour: | 99 pages |
Network
| Protocol | TCP/IP, SNMP |
| Wired LAN | |
| Network Type | IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T) |
| Data Rate | 10M/100Mbps (auto switchable) |
| Wireless | |
| Network Type | IEEE802.11n / IEEE802.11g / IEEE802.11b |
| Frequency Band | 2.4GHz |
| Channel*9 | 1-13 |
| Security | WEP64/128bit WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES) |
| Direct Connection (Wireless LAN) | Available |
Printing Solutions
| AirPrint | Available |
| Windows 10 Mobile | Available |
| Mopria | Available |
| Canon Print Service for Android | Available |
| PIXMA Cloud Link (from smartphone/tablet) | Available |
| Message in Print (for iOS/for Android) | Available |
| Easy Photo-Print Editor (for iOS/for Android) | Available |
| Canon PRINT | Available |
System Requirements
| Windows 10 / 8.1 / 7 SP1 (operation can only be guaranteed on a PC with a pre-installed Windows 7 or later.)Mac OS X 10.10.5 ~ OS X 10.11, Mac OS v10.12 ~ 10.14 |
General Specifications
| Operation Panel | |
| Display | 5.08 cm LCD |
| Language | 32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese |
| Interface | Hi-Speed USB 2.0 |
| PictBridge (Wireless/Wired LAN) | Available |
| Operating Environment*11 | |
| Temperature | 5 – 35°C |
| Humidity | 10 – 90% RH (no dew condensation) |
| Recommended Environment*12 | |
| Temperature | 15 – 30°C |
| Humidity | 10 – 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 – 40°C |
| Humidity | 5 – 95% RH (no dew condensation) |
| Quiet Mode | Available |
| Acoustic Noise (PC Print) | |
| Plain Paper (A4, B/W)*13 | 50.5dB |
| Power | AC 100-240V, 50/60Hz |
| Power Consumption | |
| OFF | 0.3W |
| Standby (scanning lamp is off) USB connection to PC | 0.8W |
| Standby (all ports connected, scanning lamp is off) [EU only – for ErP Lot 26 regulation] | 1.7W |
| Time to enter Standby mode [EU only – for ErP Lot 26 regulation] | 11m 10s. |
| Copying*14 USB connection to PC | 15W |
| Typical Electricity Consumption (TEC)*15 | 0.2kWh |
| Environment | |
| Regulation | RoHS (EU, China), WEEE (EU) |
| Duty Cycle | 5 000 pages/month |
| Dimension (WxDxH) | |
| Factory Configuration | 403 x 369 x 195 mm |
| Output/ADF trays extended | 403 x 671 x 306 mm |
| Weight | 8.1kg |
Page Yield
| Plain Paper (A4 pages) (ISO/IEC 24712 test file)*16 | Standard: GI-70 PGBK: 6 000 GI-70 C/M/Y: 7 700Economy*17: GI-70 PGBK: 8 300 GI-70 C/M/Y: 7 700 |
| Photo Paper (PP-201,10.16 x 15.24cm) (ISO/IEC 29103 test file)*16 | Standard: GI-70 PGBK: NA GI-70 C/M/Y: 2 200 |
