Product details
| Print Head / Ink | |
| Type | Permanent |
| Number of Nozzles | Total 1 280 nozzles |
| Ink Catridges | PG-745s, CL-746s |
| Printing Resolution | 4 800 (horizontal)*1 x 1 200 (vertical) dpi |
| Print Speed*2 Based on ISO/IEC 24734 Click here for Summary Report Click here for Document Print and Copy Speed Measurement Conditions | |
| Document (ESAT/Simplex) | 7.7 images per minute (black)/4.0 images per minute (colour) |
| Photo (10.16 x 15.24cm) (PP-201/Borderless) | 65s |
| Printable Width | 203.2mm |
| Printable Area | |
| Borderless Printing*3 | Top/Bottom/Right/Left margin: each 0 mm (Supported paper size: 10.16 x 15.24cm, 12.7 x 17.78cm, Square (12.7 x 12.7cm) |
| Bordered Printing | Top margin: 3mm, Bottom margin: 5mm, Left/Right margin: 3.4 mm (l: Left: 6.4 mm, Right: 6.3mm) |
| Support Media | |
| Rear Tray | Plain Paper Photo Paper Plus Glossy II (PP-201) Glossy Photo Paper “Everyday Use” (GP-508) Photo Paper Plus Glossy II (PP-208) |
| Paper Size | |
| Rear Tray | A4, A5, B5, l, LGL, 10.16 x 15.24cm,12.7 x 17.78cm, Square (12.7 x 12.7cm) [Custom size]: width 101.6mm – 215.9 mm, length 127mm – 676mm |
| Paper Size (Borderless)*4 | 10.16 x 15.24cm, 12.7 x 17.78cm, Square (12.7 x 12.7cm) |
| Paper Handling (Number) | |
| Rear Tray (Plain Paper) | A4 = 60 |
| Paper Weight | |
| Rear Tray | Plain Paper: 64-105 g/m², Canon specialty paper: maximum paper weight: 275g/m² (Photo Paper Plus Glossy II, PP-201) |
| Ink End Sensor | Dot count |
| Print Head Alignment | Manual |
Scan*5
| Scanner Type | Flatbed |
| Scanner Method | CIS (Contact Image Sensor) |
| Optical Resolution*6 | 600 x 1 200dpi |
| Scanning Bit Depth (Input/Output) | |
| Grayscale | 16bit/8bit |
| Colour | RGB each 16bit/8bit |
| Line Scanning Speed*7 | |
| Grayscale | 1.5 ms/line (300dpi) |
| Colour | 3.5 ms/line (300dpi) |
| Document Size | |
| Flatbed | A4/l (216 x 297mm) |
Copy
| Document Size | A4/l |
| Compatible Media | |
| Size | A4/A5/B5/LTR/10.16 x 15.24cm/12.7 x 17.78cm/Square 12.7 x 12.7cm) |
| Type | Plain Paper Glossy Photo Paper “Everyday Use” (GP-508) Photo Paper Plus Glossy II (PP-201) Photo Paper Plus Glossy II (PP-208) |
| Image Quality | 2 positions (Draft, Standard) |
| Copy Speed*8 Based on ISO/IEC 24734 Click here for Summary Report Click here for Document Print and Copy Speed Measurement Conditions | |
| Document (sFCOT/Simplex) | 3.0 images per minute |
| Document (sESAT/Simplex) | 2.7s |
| Multiple Copy | |
| Black/Colour: | 1 – 20 pages |
Network
| Protocol | SNMP, HTTP, TCP/IP (IPv4/IPv6) |
| Wired LAN | |
| Network Type | IEEE802.11n/IEEE802.11g/IEEE802.11b |
| Frequency Band | 2.4GHz |
| Channel*8 | 1-13 |
| Security | WEP64/128bit WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES) |
| Direct Connection (Wireless LAN) | Available (Acess Point Mode only) |
Printing Solutions
| AirPrint | Available |
| Windows 10 Mobile | Available |
| Mopria | Available |
| Canon Print Service (for Android) | Available |
| PIXMA Cloud Link (from smartphone/tablet) | Available |
| Canon PRINT | Available |
System Requirements*9
| Windows 10 / 8.1 / 7 SP1 (operation can only be guaranteed on a PC with a pre-installed Windows 7 or later.) Mac OS v10.12 ~ v 10.14, Mac OS X 10.11.6 |
General Specifications
| Operation Panel | |
| Display | LCD (3.8cm segment mono) |
| Interface | Hi-Speed USB 2.0 |
| PictBridge (Wireless) | Available |
| Operating Environment*10 | |
| Temperature | 5 – 35°C |
| Humidity | 10 – 90% RH (no dew condensation) |
| Recommended Environment*11 | |
| Temperature | 15 – 30°C |
| Humidity | 10 – 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 – 40°C |
| Humidity | 5 – 95% RH (no dew condensation) |
| Quiet Mode | Available |
| Acoustic Noise (PC Print) | |
| Plain Paper (A4, B/W)*12 | 53.5 dB |
| Power | AC 100-240V, 50/60Hz |
| Power Consumption | |
| OFF | 0.3W |
| Standby (scanning lamp is off) USB connection to PC | 1.7W |
| Standby (all ports connected, scanning lamp is off) | 1.7W |
| Time to enter Standby mode | 10min 38s |
| Copying*13 USB connection to PC | 11W |
| Environment | |
| Regulation | RoHS (EU, China), WEEE (EU) |
| Dimension (WxDxH) | |
| Factory Configuration | 435 x 316 x 145mm |
| Output/ADF trays extended | 435 x 553 x 212mm |
| Weight | 3.9kg |
Page Yield
| Plain Paper (A4 pages) (ISO/IEC 24712 test file)*14 | PG-745s: 100 pages CL-746s: 100 pages PG-745: 180 pages CL-746: 180 pages |
