Product details
| Uplink Ports | 2, 1000Mbps, Transmission Distance: Default: 0-100m |
| Network Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE802.3x |
| Switch Capacity | 12 Gbps Full duplex |
| Packet Forwarding Rate | 1.488 Mpps/port |
| PoE Ports | 4, 1000Mbps; RJ45 ports; Max. 30W Output of Single PoE Port Transmission distance:0~100m or 0~250m selected by switch |
| Power Indicator | Light on: Powering Light off: No Power |
| Network Port | 6 Ports |
| Transmission Distance | 0-100m/1000Mbps or Port 3-4 Max. 250m/10Mbps via Cat.5e or more under Extend mode |
| PoE Standard | IEEE802.3af, IEEE802.3at |
| Watchdog | Support |
| PoE Power Supply | 1/2(+), 3/6(-) |
| PoE Power Budget | 48W |
| VLAN | Support |
| Surge Protection | Common mode/RJ45 port: 6KV, Differential mode/RJ45 port: 2KV, Common mode/ Power board: 6KV, Differential mode/Power board: 1KV |
| Forwarding Mode | Store-and-forward |
| MAC Address Table | 2K |
| DIP switch indicator | Green light off: Normal/Default mode, Green light on: VLAN mode, Green light flash: Extend mode |
| ESD | Air discharge: 8KV, Contact discharge: 6KV |
| RJ-45 ACT Indicator | Green light off: Link is disconnected Green light on: Link is connected Green light flash: Data Transmitting |
| PoE Feature | All ports support MDI/MDIX |
| Power Source | Input: 100-240V AC, 50/60Hz |
| Power Consumption | <5W |
| Operating Temperature | -10°C ~50°C |
| Operating Humidity | 10%-95%, Non-condensing |
| Storage Temperature | -40°C~70°C |
| Dimensions | 200 mm x 118 mm x 44 mm |
| Weight | 600 g |
