CP-SAVW-HPU8H2-96
- 8, 1000Mbps, RJ45 ports, IEEE802.3u, IEEE802.3ab, IEEE802.3 af
- Communication standard IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T
- Surge protection 6KV commo mode, 4KV differential mode
- PoE Power 96W
- Easy and safe installation
- Estimated delivery time 14-30 days
- 18 months warranty at Genuine Warranty Center.
- Whats in the box: charging cable and block
Product details
| PoE Standard | IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.1W Spanning Tree, IEEE 802.3x flow control |
| Data Transmission Port | 1×8 RJ45, 1×2 RJ45 |
| Transmission Rate | 10/100Mbps auto-negotiate, 10/100/1000Mbps auto-negotiate |
| Transmission Distance | 10Base-T: ≤250m (CAT3,4,5 UTP), 100Base-TX: ≤100m (CAT3,4,5 UTP), 1000Base-T: ≤100m (CAT3,4,5 UTP） |
| Forwarding Mode | Store and forward |
| Transmission mode | Support Half/Full duplex Mode |
| MAC Address List | 4K |
| Case space | 1Mb |
| Jumbo Frame | 921 |
| Packet Forwarding Rate | 4.1664Mpps@64byte |
| Bandwidth | 5.6G |
| Power Indicator | Green power |
| Ethernet indicator | Yellow, Per Ethernet Port |
| DIP switch indicator | Green per PoE port, Green per uplink port |
| DIP switch | 100m:Standard mode – All ports can communicate with each other, 250m: Extend mode, port 1-8 are isolated from each other, transmission distance can up to 250m, and can communicate with port 9-10 |
| Power Input | AC100~240V, 50Hz |
| Power Consumption | Standby: ≤3W, whole: ≤96W |
| PoE Pin | 1/2+, 3/6- |
| The Port max. Rate | ≤25.4W |
| Operating Temperature | -20°C ～60°C |
| Storage Temperature | -40°C ～85°C |
| Operating Humidity | 5%～95% non-condensing |
| Heat dissipation method | Natural Heat dissipation |
| Dimensions | 201mm × 140mm × 44mm |
| Weight | 0.7kg |
