Product details
| Image Sensor | 1/2.7″ 2MP PS CMOS Image Sensor (0.9407 Centimeters) |
| Effective Pixels | 1920 (H) × 1080 (V) |
| Minimum Illumination | 0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on) |
| Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360° |
| White Balance | Auto, Natural, Street lamp, Outdoor, Manual, Regional custom |
| RAM | 128 MB |
| ROM | 128 MB |
| DORI Distance | Lens 3.6 mm: 58.9 m (Detect), 23.6 m (Observe), 11.8 m (Recognize), 5.9 m (Identify) |
| Gain Control(AGC) | Auto/ Manual |
| Lens Type | Fixed-focal |
| Close Focus Distance | 1.3 m |
| Lens | 3.6mm fixed Lens |
| Lens Mount | M12 |
| S/N Ratio | >56 dB |
| Back Light Compensation | BLC/ HLC/ WDR(120dB) |
| Angle of view | 3.6 mm: H: 84°, V: 44°, D: 105° |
| Video Compression | Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream) |
| IR Number | 2 IR LED, 2 Warm Light |
| IR | IR Range of 50 Mtr. |
| Smart IR | Support |
| Day/Night | Auto(ICR)/Color/B/W |
| IR Control | Auto, Manual |
| Stream Capability | Quad Stream |
| Frame Rate | Main stream: 2MP (1920 × 1080)@1–25/30 fps Sub stream 1: 720P@1–25/30 fps Sub stream 2: D1@1–25/30 fps Sub stream 3: D1@1fps |
| Video Format | PAL/NTSC |
| Privacy Mask | 4 areas |
| IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| ROI | Support (4 areas) |
| Audio Input | 1 Channel (RCA port) |
| Audio Output | 1 Channel (RCA port) |
| OSD | Camera title, Date & Time |
| Audio Compression | G.711a, G.711Mu, G.726, PCM, AAC |
| Alarm Out | 1 Channel out: 300 mA 12 VDC |
| Bit Rate | H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps |
| Bit Rate Control | CBR/ VBR |
| Protocol | SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast |
| SDK and API | Support |
| Ethernet | RJ-45 (10/100 Base-T) |
| Browser | IE, Chrome, Firefox |
| Mirror Function | Support |
| Resolution | 2M (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
| Noise Reduction | 3D NR |
| Smart search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Storage | SFTP, Mirco SD card (Max. 512GB) |
| Alarm Event | No SD card, SD card full, SD card error, Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Tripwire, Intrusion, Audio detection, Voltage detection, SMD, Security exception, External alarm |
| Iris Control | Fixed |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2M resolution and lower) |
| User/Host | 6 (Total bandwidth: 36 M) |
| Hardware Reset Point | Support |
| Certificates | ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report |
| Power Source | 12 VDC/PoE (802.3af) |
| Power Consumption | Basic: 1.6 W (12 VDC), 2.1 W (PoE) Max. (H.265+ intelligence on + WDR + illuminator on): 5.8 W (12 VDC), 6.9 W (PoE) |
| Weatherproof Standard | IP67 & IK10 |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | ≤95% |
| Casing | Metal |
| Dimensions | 238.5 mm × 90.7 mm × 90.7 mm |
| Weight | 720g |
