Product details
| Image Sensor | 1/2.7″ 2MP PS CMOS Image Sensor (0.9407 Centimeters) |
| Effective Pixels | 1920 (H) × 1080 (V) |
| Minimum Illumination | 0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on) |
| Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Angle Adjustment | Pan: 0°–355°, Tilt: 0°–65°, Rotation: 0°–355° |
| White Balance | Auto, Natural, Street lamp, Outdoor, Manual, Regional custom |
| RAM | 128 MB |
| ROM | 128 MB |
| DORI Distance | Lens 3.6 mm: 58.9 m (Detect), 23.6 m (Observe), 11.8 m (Recognize), 5.9 m (Identify) |
| Gain Control (AGC) | Auto/ Manual |
| Lens Type | Fixed-focal |
| Max. Aperture | F1.4 |
| Lens Mount | M12 |
| Close Focus Distance | 1.1 m |
| Lens | 3.6mm fixed Lens |
| Angle of View | 3.6 mm: H: 87°, V: 44°, D: 105° |
| Iris Control | Fixed |
| S/N Ratio | >58 dB |
| IR Number | 3 IR LED, 4 Warm Light |
| IR | IR Range of 50 Mtr. |
| Warm Light | Warm Light Range of 30 Mtr. |
| Smart Illumination | Support |
| Video Compression | Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream) |
| Back Light Compensation | BLC/ HLC/ WDR(120dB) |
| Day/Night | Auto(ICR)/Color/B/W |
| IR Control | Auto, Manual |
| Resolution | 2MP (1920 × 1080), 1.3MP (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Privacy Mask | 4 areas |
| Video Format | PAL/NTSC |
| IVS (Perimeter Protection) | Tripwire, Intrusion, SMD |
| Stream Capability | Quad Stream |
| Frame Rate | Main stream: 2MP (1920 × 1080)@1–25/30fps Sub stream 1: 720P@1–25/30fps Sub stream 2: D1@1–25/30fps Sub stream 3: D1@1fps |
| OSD | Camera title, Date & Time |
| Audio Input | 1 Channel (RCA port) |
| Audio Output | 1 Channel (RCA port) |
| Audio Compression | G.711a, G.711Mu, G.726, PCM, AAC |
| Image Rotation | 0°/90°/180°/270° (Support 90° with 2M resolution and lower) |
| Bit Rate | H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps |
| Bit Rate Control | CBR/VBR |
| Protocol | SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast |
| Ethernet | RJ-45 (10/100 Base-T) |
| SDK and API | Support |
| Alarm Event | No SD card, SD card full, SD card error, Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Tripwire, Intrusion, Audio detection, Voltage detection, External alarm, SMD, Security exception |
| User/ Host | 6 (Total bandwidth: 36 M) |
| Mirror Function | Support |
| Audio | Built-in Mic |
| Smart IR | Support |
| Alarm IN | 1 Channel in: 5 mA 3–5 VDC |
| Alarm Out | 1 Channel out: 300 mA 12 VDC |
| Cyber Security | AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot |
| Hardware Reset Point | Support |
| Certificates | ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report |
| Power Source | 12 VDC/PoE (802.3af) |
| Dual Power Backup | When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart |
| Power Consumption | Basic: 2.1 W (12 VDC), 2.6 W (PoE); Max.: 6.2 W (12 VDC), 7.5 W (PoE) (H.265 + intelligence on+ WDR + illuminator intensity) |
| Browser | IE: IE11, Chrome, Firefox |
| Storage | SFTP, Mirco SD card (Max. 512GB) |
| Weatherproof Standard | IP67 & IK10 |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F |
| Operating Humidity | ≤95% (RH), non-condensing |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | ≤95% (RH), non-condensing |
| Casing | Metal |
| Dimension | 81.0 mm × 109.9 mm |
| Weight | 350g |
