Product details
| Image Sensor | 1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter) |
| Effective Pixels | 1920(H) x 1080(V) |
| Minimum Illumination | Color: 0.005 Lux@F1.6, B/W: 0.0005 Lux@F1.6, 0 Lux@F1.6 (IR on) |
| Focus Control | Auto/Semi-Auto/Manual |
| RAM | 512 MB |
| ROM | 256 MB |
| White Balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp |
| Lens | 3.95 mm–177.75 mm |
| Max. Aperture | F1.6–F4.95 |
| Angle of view | H: 65.7°–1.9°, V: 39.4°–1.1°, D: 73.1°–2.1° |
| Close Focus Distance | 0.1 Mtr. – 1 Mtr. |
| Iris Control | Auto/Manual |
| DORI Distance | 2451.7 Mtr. (Detect), 972.9 Mtr. (Observe), 490.3 Mtr. (Recognize), 245.2 Mtr. (Identify) |
| Electronic Shutter | 1/1 s–1/30,000 s |
| Back Light Compensation | BLC / HLC / WDR(120dB) |
| S/N Ratio | ≥ 56 dB |
| Optical Zoom | 45× |
| Digital Zoom | 16x |
| Image Rotation | 180° |
| Pan & Tilt Range | Pan: 0° to 360° endless, Tilt: –20° to +90°, auto flip 180° |
| Manual Speed | Pan: 0.1° ~260° /s, Tilt: 0.1° ~120° /s |
| Preset Speed | Pan: 300°/s, Tilt: 200°/s |
| Image Stabilization | Electronic (EIS) |
| Privacy Masking | Up to 24 Areas can be set, with up to 8 areas in the same view |
| Special Features | Up to 300 Presets, 5 Pattern, 8 (up to 32 presets per tour) Tour, 5 Scan |
| Idle Motion | Preset/ Tour/ Pattern/ Scanning |
| IR Distance | 300 Mtr. |
| IR Number | 6 (IR) |
| IR Control | Zoom Prio, Manual, Smart IR, Off |
| Day/Night | Auto (ICR)/Color/B/W |
| Gain Control | Auto/Manual |
| Video Format | PAL/NTSC |
| OSD | Camera title, Date & Time |
| Video Compression | Instastream, H.265, H.264+, H.264H, H.264B, H.264, MJPEG(Sub Stream) |
| Resolution | 2MP (1920 × 1080), 1MP (1280 × 720), D1 (704 × 576), CIF (352 × 288) |
| Frame Rate | Main stream: 2MP/1MP/D1 @(1–25/30 fps) Sub stream 1: 2MP/1MP/D1 @(1–25/30 fps) Sub stream 2:D1/CIF @(1–25/30 fps) Sub stream 3: D1/CIF @(1–25/30 fps) |
| Stream Capability | Quad Stream |
| Bit Rate | H264: 64 kbps–8192 kbps, H265: 25 kbps–6400 kbps |
| Bit Rate Control | CBR/VBR |
| ROI | Support |
| Noise Reduction | 2D/3D DNR |
| Two-way Talk | Support |
| Audio In | 1 channel |
| Audio Out | 1 channel |
| Audio Compression | PCM, G.711a, G.711Mu, G.726, MPEG2-Layer2, G722.1 |
| Alarm I/O | 7/2 channel In/Out |
| User/Host | 20 (total bandwidth: 64 Mbps) |
| Ethernet | RJ-45 (10/100Base-T) |
| Alarm Event | Motion/Tampering detection, audio detection, network disconnection detection, IP conflict detection, memory card state detection, memory space detection |
| Protocol | IPv4, IPv6, HTTP, HTTPS, ARP, RTSPS, SMTP, SFTP, DHCP, DNS, UPnP, NTP, Multicast, NFS, PPPoE, SNMP V1/V2/V3, ICMP,IGMP, ONVIF (Profile S, Profile G, Profile T), Unicast, Multicast |
| IVS (Optional) | Tripwire, Intrusion, Object Abandon/ Missing, SMD, Face Detection |
| Storage | SFTP, NAS, Micro SD card (support max. 512 GB) |
| Browser | Microsoft Edge and Chrome |
| Operating Temperature | –40 °C to +70 °C |
| Operating Humidity | ≤ 95% RH, Non condensing |
| SR 332 | Quality Level II |
| Weatherproof Standard | IP67, IK10, TVS 8000V lightning proof, surge protection, voltage transient protection |
| Certificates | MTBF Certificate from STQC, EMI/EMC, ISO9001, CE, FCC and RoHS, BIS, STQC approved compliance report |
| Power Source | 24 VDC, 2.5 A ± 25% PoE+ (802.3at) |
| Power Consumption | 24 VDC, 2.5 A ± 25%: Basic: 13 W, Max: 25 W (illuminator + PTZ) , PoE+ (802.3at): Basic: 13 W, Max: 25 W (illuminator + PTZ) |
| Casing | Metal |
| Dimension | 337.4mm × 209mm |
| Weight | 5.9 kg |
