Product details
| Image Sensor | 1/2.8” 5MP PS CMOS Image sensor (0.9071 centimeter) |
| Effective Pixels | 2960(H) x 1668(V) |
| Minimum Illumination | Color: 0.005 Lux@F1.6, B/W: 0.0005 Lux@F1.6, 0 Lux@F1.6 (IR on) |
| Focus Control | Auto/Semi-Auto/Manual |
| RAM | 1 GB |
| ROM | 4 GB |
| White Balance | Auto, Indoor, Outdoor, Tracking, Manual, Sodium lamp, Natural light, Street lamp |
| Lens | 3.95 mm–177.75 mm |
| Max. Aperture | F1.6–F4.95 |
| Angle of View | H: 65.7°–1.9°, V: 39.4°–1.1°, D: 73.1°–2.1° |
| Close Focus Distance | 0.1 Mtr. – 1 Mtr. |
| Iris Control | Auto/Manual |
| DORI Distance | 2451.7 Mtr. (Detect), 972.9 Mtr. (Observe), 490.3 Mtr. (Recognize), 245.2 Mtr. (Identify) |
| Back Light Compensation | BLC/ HLC/ WDR(120dB) |
| S/N Ratio | ≥ 55 dB |
| Optical Zoom | 45× |
| Digital zoom | 16x |
| Pan & Tilt Range | Pan: 0° to 360° endless, Tilt: –20° to +90°, auto flip 180° |
| Power-off Memory | Support |
| Manual Speed | Pan: 0.1° ~260° /s, Tilt: 0.1° ~120° /s |
| Preset Speed | Pan: 300°/s, Tilt: 200°/s |
| Image Stabilization | Electronic (EIS) |
| Privacy Masking | Up to 24 Areas can be set, with up to 8 areas in the same view |
| Special Features | Up to 300 Presets, 5 Pattern, 8 (up to 32 presets per tour) Tour, 5 Scan |
| Defog | Electronic |
| IR | IR Range of 300 Mtr. |
| IR Number | 6 IR |
| IR Control | Zoom Prio, Manual, Smart IR, Off |
| Day/Night | Auto (ICR)/Color/B/W |
| Gain Control | Auto/Manual |
| Video Format | PAL/NTSC |
| OSD | Camera title, Date & Time |
| Video Compression | Instastream, H.265, H.264, H.264H, H.264B MJPEG (Sub Stream) |
| Stream Capability | Triple Stream |
| Resolution | 5MP (2960 × 1668), 4MP (2560 x 1440), 3MP (2304 x 1296), 2MP (1920 × 1080), 720p (1280 × 720), D1, CIF |
| Frame Rate | Main stream: 5MP (2960 × 1668)@1–25/30fps, 4MP (2560 x 1440)@1–25/30fps, 3MP (2304 x 1296)@1–25/30fps, 2MP (1920 × 1080)@1–25/30fps, 720p (1280 × 720))@1–25/30fps, D1@1– 25/30fps Sub stream 1: D1/VGA/CIF@25fps Sub stream 2: 720P@(1–25/30 fps) |
| Bit Rate | H265: 25 kbps–6400 kbps, H264: 64 kbps–10496 kbps |
| Bit Rate Control | CBR/VBR |
| Noise Reduction | 2D NR/3D NR |
| Audio Out | 1 Channel |
| Audio Compression | PCM, G.711a, G.711Mu, G.726, MPEG2-Layer2, G722.1, G729, G723 , AAC |
| Alarm IN | 2 Channel |
| Alarm Out | 1 Channel |
| Alarm Linkage | Capture, Recording, Send email, Preset, Tour, Pattern, Alarm digital output |
| Alarm Event | Motion/Tampering detection, audio detection, network disconnection detection, IP conflict detection, memory card state detection, memory space detection |
| User/Host | 20 (total bandwidth: 64 Mbps) |
| Ethernet | 1 × RJ-45 (10/100 Base-T) |
| PTZ Protocol | CP-SD Pelco-P/D (auto recognition) |
| Protocol | IPv4, IPv6, HTTP, HTTPS, ARP, RTSPS, SMTP, SFTP, DHCP, DNS, UPnP, NTP, Multicast, NFS, PPPoE, SNMP V3, TLS Version 1.2, ICMP,IGMP, ONVIF (Profile S, Profile G, Profile T), Unicast, Multicast |
| IVS (Optional) | Tripwire, Intrusion, Object Abandon/ Missing, SMD, Face Detection. |
| RS-485 | 1(Bit range: 1200 bps–9600 bps) |
| Storage | SFTP, NAS, Mirco SD card (Max. 512GB) |
| Browser | Microsoft Edge and Chrome |
| Certificates | ISO9001, CE, FCC and RoHS |
| Weatherproof Standard | IP67, IK10, TVS 8000V lightning proof, surge protection, voltage transient protection |
| Power Source | 24 VDC, 2.5 A ± 25% PoE+ (802.3at) |
| Power Consumption | Basic: 13 W Max: 25 |
| Operating Temperature | –40 °C to +70 °C |
| Operating Humidity | ≤ 95% RH, Non condensing |
| Dimension | 337.4mm × 209mm |
| Weight | 5900g |
