Product details
| IP Camera Input | 4 channel |
| Processor | Embedded microprocessor |
| Two-way Talk | 1 channel Input, 1 channel Output |
| User Interface | GUI |
| Video Output | 1VGA, 2TV,1 HDMI |
| Video Resolution | 800×600 |
| Video Compression | H.265/smart H.265 /H.264/smart H.264 |
| Resolution | 4 ch@4MP realtime recording |
| Motion Detection | MD Zones:396(PAL:22×18,NT SC:22×15) |
| Video Display Split | 1/4 |
| Video Loss | Supports |
| Camera Blank | Supports |
| Audio Compression | G.711A/G.711U/PCM |
| Alarm Input | 9 channels, Alarm1–8 are local alarm input, Alarm 9 is pulse input. |
| Alarm Output | 2 channels, 1 relay out, 1 Controllable 12V out |
| Hard Disk | 1 SATA |
| Smart Phone | iPhone, iPad, Android Phone |
| Trigger Events | Recording, PTZ, Tour, Alarm, Email, FTP, Buzzer & Screen tips |
| Memory | 1 SD card, Up to 256 GB |
| Recording Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
| Search Mode | Time/Date, Alarm, Motion Detection & Exact search (accurate to second) |
| Playback | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom |
| Backup Mode | USB Device/Network |
| User Account | 128 users |
| Interface Ports | 1VGA, 2TV,1HDMI, 3 USB 2.0, 3 RS232, 2 RS485, Heater(Optional) |
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Ethernet | RJ-45 Port (10/100Mbps) |
| Protocols | TCP/IP, UDP, DHCP, DDNS, FTP, Email, Alarm Server |
| Power Supply | DC 6V~36V |
| Power Consumption | <10.2W (Without HDD) |
| Working Temperature | -30°C (with heater)~ +70°C (-22°F ~ +158°F) |
| Working Humidity | 10 ~ 90% RH |
| Dimension | 180mm×190mm×50mm |
| Net Weight | 1.92Kg (without HDD) |
