CP-UNR-4K2041-4PG
Support up to 4Ch. IP Camera Input
H.265/H.264 dual codec decoding
Up to 8MP resolution preview and playback
Max 80Mbps incoming bandwidth
Support 1 SATA HDDs up to 8TB, 2 USB ports(2.0), 4 PoE Ports
HDMI / VGA simultaneous video output
Support 4G Network (Embedded 4G Sim Card slot)
Support Wi-Fi, ONVIF Version 2.4 conformance
Support Multi-brand network cameras
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro
- Estimated delivery time 14-30 days
- 18 months warranty at Genuine Warranty Center.
- Whats in the box: charging cable and block
Product details
| Processor | Dual-core embedded processor |
| Operating System | Embedded LINUX |
| IP Camera Input | 4 channel |
| Two-way Talk | 1 channel Input, 1 channel Output, RCA |
| User Interface | GUI |
| Video Output | 1 HDMI, 1 VGA |
| Video Resolution | 3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Video Recording | Max 80 Mbps, 6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc. |
| Video Display Split | 1/4 |
| Channel | 4 |
| Bandwidth Incoming | 80 |
| Motion Detection | MD Zones: 396(22×18). |
| Video Loss | Supports |
| Smart Phone | iPhone, iPad, Android Phone |
| Hard Disk | 1 SATA III ports, up to 8TB |
| Trigger Events | Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips |
| Recording Mode | Manual, Schedule(Regular(Continuous), MD, Stop |
| Search Mode | Time/Date, MD & Exact search (accurate to second) |
| Backup Mode | USB Device / Network |
| Playback | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom |
| Max User Account | 128 users |
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Ethernet | 1 RJ-45 port (10/100Mbps), 4 PoE Ports (IEEE802.3at) |
| Interface Ports | 1 HDMI, 1 VGA, 2 USB Ports(2.0) |
| Protocols | HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search, ONVIF Version 2.4, CGI Conformant |
| Power Supply | Single DC 48V/125A |
| Power Consumption | NVR: <5.3W (without HDD); PoE: Max 25.5w for single port, 50w in total |
| Working Temp | -10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimension | 260mm x 224.9mm x 47.6mm |
| Weight | 0.8kg (without HDD) |
