Product details
| Processor | Industrial-grade embedded processor |
| Operating System | Embedded LINUX |
| User Interface | Web/operating in local GUI |
| Video Output | 1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI |
| IP Camera Input | 4 channel |
| Performance | 4 channel |
| Video Resolution | 8MP; 6MP; 5MP; 4MP; 3MP; 1080P; 720P; D1 |
| Video Recording | Access: 160 Mbps; Storage: 160 Mbps; Forward: 64 Mbps |
| Video Display Split | 1 /4 views |
| Video Compression | H.265/Smart H.264+/H.264/MJPEG |
| Channel | 4 |
| AI Search | Search for pictures by channel, time and face attributes |
| AI by Camera | Search for pictures by channel, time and event type |
| Motion Detection | Supports |
| Face | Search for pictures by channel, time and face attributes |
| Decoding Capability | 4 × 1080P@30fps |
| Alarm Linkage | Recording, snapshot, audio, buzzer, log, preset, and email |
| Video Loss | Supports |
| General Alarm | Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm |
| Smart Phone | iPhone, iPad, Android Phone |
| Anomaly Alarm | Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception |
| Audio Compression | PCM/G711A/G711U/G726/AAC |
| Audio Input | 1 Channel RCA input |
| Audio Output | 1 Channel RCA output |
| Hard Disk | 2 SATA III ports, up to 10TB for a single HDD. The maximum HDD capacity varies with environment temperature |
| Alarm Input | 4 Channel |
| Alarm Output | 2 Channel |
| Recording Mode | Manual record; alarm recording; SMD recording; smart recording |
| Backup Mode | USB storage device |
| Playback | Play/pause/stop/slow/quick/backward/by frame Full screen, backup (video clip/file), partial zoom in, and audio on/off |
| Ethernet | 1 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port |
| Interface Ports | 2 USB Ports (1 × front USB2.0; 1 × back USB2.0) |
| PoE | 4 PoE Ports |
| Playback | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search, P2P, auto register, ONVIF (profile T/S/G); CGI; SDK |
| Power Supply | DC48 V/53 V, 1.5 A/1.36 A |
| Power Consumption | < 10 W (HDD not included, idling) Total output power of PoE is 36W, the maximum output power of a single port is 25.5W |
| Working Temp | -10°C to +55°C (+10 °F to +131 °F) |
| Dimension | 375 mm × 282.4 mm × 53 mm (W × L × H) |
| Working Humidity | 10%~93% |
| Operating Altitude | 3000m |
| Weight | 1.58 kg |
| Certificate | CE, FCC, RoHS, BIS, Onvif |
