Product details
| Processor | Industrial-grade processor |
| IP Camera Input | 16 Channels |
| Operating System | Embedded LINUX |
| User Interface | Web, Local GUI |
| Perimeter Performance AI by NVR | 2 channels, 10 IVS rules for each channel |
| Perimeter Performance of AI by Camera | All channels (8 targets/s) |
| Face Detection AI by NVR | 1 Channel (up to 12 face images/s each channel) |
| Video Output | 1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Abnormality Alarm | Camera disconnection, Storage error, Disk full, IP conflict, MAC conflict, Login locked, Cybersecurity exception |
| Face Recognition AI by NVR | 8 Channel FD (by camera) + FR (by NVR), image stream: 12 face images/s 1 Channel FD (by NVR) + FR (by NVR), video stream: 12 face images/s |
| Face Recognition AI by Camera | All Channels (8 targets/s) |
| Network Bandwidth | AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing |
| Video Display Split | 1st Screen: 1/4/8/9/16; 2nd Screen: 1/4/8/9 |
| ANPR by Camera (Number of Channels) | All Channels (4 targets/s) |
| License Plate Database Capacity | 1. Create up to 20,000 plate numbers; 2. Blocklist and allowlist |
| Audio Input | 1 Channel RCA |
| Audio Output | Audio Output |
| Video Resolution | 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 2MP, 960p, 720p, D1, CIF |
| Video Compression | Instastream, H.265, H.264+, H.264, MJPEG |
| Alarm Input | 16 Channel |
| Alarm Output | 4 Channels |
| Disk Group | Support |
| Hard Disk | 4 SATA ports, up to 16 TB. The maximum HDD capacity varies with environment temperature |
| Alarm Linkage | Record, Snapshot, IPC external alarm output, Audio, Buzzer, Log, Preset, Email |
| Multi-channel Playback | Up to 16 Channels |
| Interface Ports | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port), 1 HDMI, 1 VGA, 1 RS232, |
| Ethernet | 2 (10/100/1000 Mbps Ethernet port, RJ-45) |
| Protocols | HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, auto register, ONVIF 22.06(Profile T, Profile S, Profile G), CGI, SDK |
| Backup Method | USB device and network |
| SMD Plus by NVR | 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, Rain and lighting condition change |
| Smart Phone | iOS, Android |
| Browser | Chrome, IE9 and later, Firefox |
| Power Supply | 100–240 VAC, 50-60Hz |
| Power Consumption | <10 W (without HDD) |
| Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
| Operating Humidity | 10%–93% (RH), non-condensing |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Dimension | 440.0 mm × 415.6 mm x 76.0 mm |
| Weight | 4.25 kg |
