Product details
| Processor | Quad-core embedded processor |
| Operating System | Embedded LINUX |
| Two-way Talk | 1 channel Input, 1 channel Output, RCA |
| User Interface | GUI |
| Video Output | 2 HDMI, 1 VGA |
| Video Resolution | 3840× 2160, 1920× 1080, 1280× 1024, 1280× 720, 1024× 768 |
| Channel | 16 channel |
| Motion Detection | MD Zones: 396(22×18). |
| Video Loss | supports |
| Bandwidth Incoming | 320 |
| Alarm Input | 16 channel |
| Alarm Output | 6 channel |
| Smart Phone | iPhone, iPad, Android Phone |
| Hard Disk | 4 SATA ports, up to 32TB, 1 eSATA port |
| Hard Disk | 4 SATA ports, up to 32TB |
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Recording Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate tosecond) |
| Backup Mode | USB Device/Network/Internal SATA burner/eSATA Device |
| Playback | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom |
| Max User Account | 128 users |
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Ethernet | 1 RJ-45 port (10/100/1000Mbps) ,1 Independent 1000Mbps Ethernet Port , 16 ports (IEEE802.3af/at) |
| Interface Ports | 2 HDMI, 1 VGA, 3 USB, 1 RS485, 1 RS232, 1 RJ45 |
| Protocols | HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, SSL, IGMP, DNS, 802.1x, IP Filter,PPPOE, DDNS, FTP, Alarm Server,ONVIF ( Profile S ) |
| Power Supply | single, AC 100~240V, 50/60 Hz |
| Power Consumption | <17.5W (without HDD) |
| Working Temp | -10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimension | 440mm×411.1mm×94.9mm (17.3 |
| Weight | 4.65kg (without HDD) |
