Product details
| Processor | Quad-core embedded processor |
| Operating System | Embedded LINUX |
| Two-way Talk | 1 Channel Input, 2 Channel Output, RCA |
| User Interface | GUI |
| Video Output | 2 HDMI, 2 VGA |
| Video Resolution | HDMI1: 3840 × 2160, 1920 × 1080,1280 × 1024, 1280 × 720,1024 × 768, VGA1: 1920 × 1080, 1280 × 1024, 1280 × 720,1024 × 768, HDMI2/VGA2: 1920 × 1080 |
| Video Recording | Max 320Mbps |
| Video Display Split | 1st screen: 1/4/8/9/16/25/36 , 2nd screen: 1/4/8/9/16 |
| Video Compression | Instastream/H.265+/Smart H.264+/H.264/MJPEG |
| Channel | 32 channel |
| OSD | Camera title, Time, Camera lock, Motion detection, Recording |
| Motion Detection | MD Zones: 396(22×18). |
| Video Loss | supports |
| Alarm Input | 16 Channel |
| Alarm Output | 6 Channel |
| Smart Phone | iPhone, iPad, Android Phone |
| Hard Disk | 4 SATA ports, up to 10TB, 1 eSATA port |
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, Snapshot, Buzzer and Screen Tips |
| Recording Mode | Manual, Schedule (Regular, MD (Motion Detection) , Alarm, IVS), Stop |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Backup Mode | USB Device/Network/eSATA Device |
| Playback | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Max User Account | 128 users |
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Interface Ports | 3 USB Ports (2 Rear USB 3.0, 1 Front USB 2.0), 1 RS232, 1 RS485 |
| Protocols | HTTP, HTTPS, TCP/IP, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search, ONVIF 2.4, SDK, CGI |
| Power Supply | Single, AC 100~240V, 50/60 Hz |
| Power Consumption | <16.7W (without HDD) |
| Working Temp | -10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimension | 440mm x 411.2mm x 76mm |
| Weight | 4.3kg (without HDD) |
