CP-USC-TC51PL3C

CP-USC-TC51PL3C

Rated 0 out of 5

0 Reviews

In stock

1/2.7” 5MP PS CMOS Image Sensor (0.9407 cm)

Max. 25fps@5MP (16:9 video output)

DWDR, Day/Night (ICR), 2D-DNR, AWB, AGC, BLC, HLC

3.6mm fixed lens (2.8mm optional)

IR Range of 30 Mtrs., IP67

Support Built-in Mic

OSD Menu, control over coaxial cable, 2D-DNR

CVI/CVBS/AHD/TVI Switchable

Product details

Image Sensor	1/2.7
Minimum Illumination	0.02 Lux/F2.0, 30 IRE, 0 Lux IR on
Max. Resolution	2880 (H) × 1620 (V)
Shutter Speed	PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s
White Balance	Auto, Manual
Lens Mount	M12
Gain Control (AGC)	Auto
Max. Aperture	F2.0
Lens	3.6mm (2.8mm optional)
Close Focus Distance	3.6 mm: 1.2 m, 2.8 mm: 0.8 m
DORI Distance	3.6mm: 80.0m (Detect) 32m(Observe) 16m(Recognize) 8m(Identify)2.8mm: 56.0m (Detect) 22.4m(Observe) 11.2m(Recognize) 5.6m(Identify)
Lens Type	Fixed
Angle of View	3.6 mm: 104° × 88° × 46°, 2.8 mm: 125° × 106° × 56°
Back Light Compensation	BLC, HLC, DWDR
Resolution	5M (2880×1620), 4M (2560×1440), 2M (1920×1080), 960H (960 × 576/960 × 480)
Video Output	Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Frame Rate	CVI: PAL: 5M@25 fps, 4M@25 fps, 2M@25 fps , NTSC: 5M@25 fps, 4M@30 fps, 2M@30 fps AHD: PAL: 4M@25 fps, NTSC: 4M@30 fps, TVI: PAL: 4M@25 fps, NTSC: 4M@30 fps, CVBS: 960H
Noise Reduction	2D DNR
Iris Control	Fixed
Audio Interface	Audio Interface
Day/Night	Auto (ICR)/ Manua
Mirror Function	Support
IR Control	Auto, Manual
IR	IR Range of 30 Mtr.,
Smart IR	Support
Operating Humidity	<95% (RH), non-condensing
Operating Temperature	–40°C to +55°C (–40°F to +131°F)
Power Source	12 VDC ± 30%
Power Consumption	Max 3.7W (12V DC, IR on)
Dimension	69.8 mm × 69.8 mm × 149.3 mm (2.75
Net Weight	0.15Kg
