Product details
| Processor | Embedded processor |
| Operating System | Embedded LINUX |
| IP Camera Input | 4+1: each channel up to 2MP |
| Two-way Talk | Reuse audio in/out, RCA |
| User Interface | GUI |
| Video Input | 4 channel, BNC |
| Video Output | 1 HDMI, 1 VGA |
| Compression | Instastream/H.265/H.264+/H.264 |
| Video Resolution | 1920×1080, 1280×1024, 1280×720 |
| Resolution | 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Video Recording | Main Stream: 1080N/720P/960H/D1/CIF (1~25/30fps), Sub stream CIF : (1~15fps) |
| Video Display Split | 1/4 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Bit Rate | 32Kbps ~ 4096Kbps Per Channel |
| Audio Input | 1 channel, RCA |
| Audio Output | 1 channel, RCA |
| Motion Detection | Support |
| Video Loss | Support |
| Audio Compression | AAC (only for the 1st channel), G.711A, G.711U, PCM |
| Camera Blank | Support |
| Smart Phone | iPhone, iPad, Android Phone |
| Hard Disk | 1 SATA port, up to 6TB |
| Audio Sample Rate | 8KHz, 16 bit Per Channel |
| Audio Bit Rate | 64Kbps Per Channel |
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Playback | 1/4 Ch. |
| Recording Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Search Mode | Time/Date, MD & Exact search (accurate to second) |
| Playback | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom |
| Backup Mode | USB Device/Network |
| Interface Ports | 2 USB Ports (2.0) |
| Max User Account | 128 users |
| Record Interval | 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Ethernet | RJ-45 port (100M) |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter ,DDNS, FTP, Alarm Server, InstaOn, IP Search, ONVIF 16.12, CGI Conformant |
| Power Supply | DC12V/1.5A |
| Power Consumption | <10W(without HDD) |
| Working Temp | -10°C ~ +45°C (+14°F ~ +113°F), 10 ~ 90% RH |
| Dimension | 197mm×192mm×41mm |
| Weight | 0.56kg (without HDD) |
