Product details
| Product Name | MAG PANO 100R PZ |
| Case Form Factor | Mid Tower |
| Motherboard Form Factor Support | Regular: ATX / Micro-ATX / Mini-ITX; Back-connect: ATX / Micro-ATX |
| I/O Ports | 1 x USB 20Gbps Type-C; 2 x USB 5Gbps Type-A; 1 x Audio-Out / Mic-in; 1 x LED Switch Button; 1 x Power Button |
| Drive Mount Support | 3 x 2.5″; 2 x 2.5″/3.5″ combo |
| Expansion Slots | 8 |
| Maximum GPU Length | 380 mm / 14.96 inches |
| Maximum CPU Cooler Height | 166 mm / 6.54 inches |
| Power Supply Support | ATX |
| Maximum PSU Length | 200 mm / 7.87 inches |
| Fan Size Support | Top: 3 x 120 mm / 3 x 140 mm; Front: NA; Rear: 1 x 120 mm; Side: 3 x 120 mm / 2 x 140 mm; Bottom: 3 x 120 mm / 2 x 140 mm / 2 x 160 mm |
| Pre-installed Fan Size | Side: 3 x 120 mm; Rear: 1 x 120 mm |
| Pre-installed Fan Type | Side: 3 x ARGB Reverse-blade; Rear: 1 x ARGB |
| Radiator Size Support | Top: 120 / 240 / 360 mm; Front: NA; Rear: 120 mm; Side: 120 / 240 / 360 mm; Bottom: 120 / 240 / 360 mm |
| Dimensions (DxWxH) | 518.7 x 290 x 482 mm / 20.42 x 11.42 x 18.98 inches |
