Product details
| Brand | NZXT |
|---|---|
| Model | PA-2G2BW-UK |
| Color | White |
|---|---|
| Type | ATX12V v3.1 / EPS12V v2.92 |
| Maximum Power | 1200 W |
| Fans | 1 x 135 mm FDB |
| PFC | Active @0.99 |
| Max PSU Length | 160 mm |
| Modular | Full Modular |
| Energy-Efficient | 80 PLUS GOLD Certified |
| Protection | OVP (Over Voltage), UVP (Under Voltage), SCP (Short Circuit), OTP (Over Temp), OPP (Over Power), OCP (Over Current) |
| Input Voltage | 100 – 240 V |
| Input Frequency Range | 50/60 Hz |
| Output | +3.3V@22A, +5V@22A, +12V@100A, +5VSB@3A |
| MTBF | >100,000 Hours |
| Approvals | FCC, Canada, CE, CB(IEC 62368-1), UKCA, CCC, BSMI, BIS, RCM, UAE, TUV, cTUVus, KC, CP65 |
| Connectors | 24-pin ATX Power Cable: 600mm with nylon sleeving, Output Connectors: 1 4+4-pin CPU Power Cable: 700mm with nylon sleeving, Output Connectors: 1 8-pin CPU Power Cable: 700mm with nylon sleeving, Output Connectors: 1 6+2-pin PCIe Power Cable: 650mm with nylon sleeving, Output Connectors: 3 16-pin (12+4) 12V-2×6 PCIe Cable: 650mm with nylon sleeving, Output Connectors: 1 SATA Cable: 500+150mm, Output Connectors: 12 Peripherals Cable: 500+150mm, Output Connectors: 4 |
| Dimensions | 150 x 86 x 160 mm |
|---|
