Name: NZXT N7 B550 (Wi-Fi) Motherboard AMD AM4 – Black
SKU: 17927
Availability: InStock

NZXT N7 B550 (Wi-Fi) Motherboard AMD AM4 – Black

Rated 0 out of 5

0 Reviews

In stock

(-71%)

WiFi 6E connectivity
Digital RGB lighting control through NZXT CAM
Digital fan control for fan profiles within NZXT CAM for seven independent fan channels
Integrated rear I/O shield and efficient layout
Compatible with 3rd Gen AMD™ Ryzen™ processors (3000, 4000, and 5000 Series Processors)
Intel® Wi-Fi 6E wireless connectivity and Bluetooth V5.2

Estimated delivery time 14-30 days
18 months warranty at Genuine Warranty Center.
Whats in the box: charging cable and block

Product details

Product Model	N7-B55XT-B1
CPU & Socket	AMD Socket AM4 Ryzen™ Processors (3000, 4000, and 5000 Series Processors) – Supported AMD Ryzen™ 5 3400G and Ryzen™ 3200G – Not Supported
Chipset	AMD® B550
Memory	4 x DIMM, Max. 128GB, DDR4 4666+ MHz – OC Frequency (Vermeer CPUs) 4666+ MHz – OC Frequency (Matisse CPUs) 4733+ MHz – OC Frequency (Renoir APUs) 3200/2933/2667/2400/2133 – Base Frequency ECC & non-ECC, un-buffered memory type Dual-channel memory architecture XMP Supported
Integrated Graphics	AMD Radeon™ Vega Series Graphics in Ryzen Series APU – HDMI HDMI™ with max. resolution of 4096×2160@60Hz Maximum shared memory of 16GB with 32GB installed Microsoft PlayReady® Supported
Multi-GPU Support	Supports AMD 2-Way CrossFireX™ Technology
Storage	1 x M.2 Type 2242/2260/2280 (x4 mode) – (Vermeer & Matisse – PCIe 4.0, Renoir – PCIe 3.0) 1 x M.2 Type 2242/2260/2280 (PCIe 3.0 x2 & SATA mode) 6 x SATA 6Gb/s – (M2_2 and SATA3_5_6 share lanes) RAID 0/1/5/10 Supported
LAN	Realtek® RTL8125BG 2.5G
Wireless	Intel® Dual-Band Wireless – AX210 Wi-Fi 6E 802.11 a/b/g/n/ac/ax Protocol 2.4 / 5 / 6GHz Frequency Bands Supports MU-MIMO
Bluetooth	Bluetooth V5.2
Audio	Realtek® ALC1220 Codec 8-Channel High Definition Audio, 32-bit / 192KHz DAC Nichicon Fine Gold Series Audio Capacitors
Rear I/O	1 x USB 3.2 Gen 2 Type-C 3 x USB 3.2 Gen 2 Type-A 4 x USB 3.2 Gen 1 ports 2 x USB 2.0 ports 1 x HDMI 2.1 2 x Wireless Antenna (2T2R) 1 x LAN (RJ45) Port 1 x 5.1-Channel Audio Jacks 1 x Optical S/PDIF 1 x BIOS Flashback Button 1 x Clear CMOS Button
Expansion Slots	1 x PCIe x16 (x16 mode) – (Vermeer & Matisse – PCIe 4.0, Renoir – PCIe 3.0) 1 x PCIe x16 (x4 mode) 2 x PCIe 3.0 x1
Internal I/O	1 x 24-pin EATX power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin CPU_FAN connector 1 x 4-pin AIO_PUMP connector (Up to 24W) 5 x 4-pin SYS_FAN connectors (Up to 24W) 1 x CPU_FAN Connector (Up to 24W) 2 x NZXT RGB LED connectors 1 x 5V Addressable RGB connector 1 x 12V RGB connector 1 x M.2 (M Key), Type 2242/2260/2280 – (PCIe 4.0/3.0 x4 mode), 1 (PCIe 3.0 x2 & SATA mode) 1 x M.2 (E Key) (For wireless cards) 6 x SATA 6Gbps Ports 1 x USB 3.2 Gen 2 Header (Type-C) 1 x USB 3.2 Gen 1 Header (Up to 2 ports) 3 x USB 2.0 Header (Up to 6 ports) 1 x Front Panel Audio 1 x Power Button 1 x Reset Button 4 x POST LEDs
Operating System	Microsoft® Windows® 10 (64-bit)
Form Factor	ATX
Warranty	3 Years
Note	***Features, Specifications, Price are subject to change without notice.
