Product details
| Graphics Card Specifications | |
|---|---|
| Graphics Engine | AMD Radeon™ RX 9070 XT |
| Model Name | RX9070XT 16G-E/OC/WHITE |
| Series | Red Devil |
| Stream Processor | 4096 Units |
| Video Memory | 16GB GDDR6 |
| Memory Speed | 20.0 Gbps |
| Memory Interface | 256-bit |
| Engine Clock (OC) | up to 2520MHz (Game)¹ up to 3060MHz (Boost)² |
| Engine Clock (STD/Silent) | up to 2460MHz (Game)¹ up to 3010MHz (Boost)² |
| Bus Standard | PCIE 5.0 x16 |
| Standard Display Connectors | 1 x HDMI 2.1b，3 x DisplayPort 2.1a |
| Feature Support | |
| DirectX® Support | 12 |
| OpenGL | 4.6 |
| AMD Eyefinity Technology | Support |
| AMD Stream Technology | Support |
| AMD Smart Access Memory | Support |
| Maximum Resolution | DisplayPort: 7680×4320 HDMI: 7680×4320 |
| Power Specs + Board Dimensions | |
| Board Dimensions | 340mm × 132mm × 69mm 352mm × 149mm × 69mm (with bracket) |
| Slot | 3 |
| Minimum System Power requirement (W) | 900W |
| Extension Power Connector | Three 8-pin PCI Express Power connectors |
| ¹ Game clock is the expected GPU clock when running typical gaming applications. ² Boost clock is the maximum frequency achievable on the GPU running a bursty workload. | |
