Product details
| Graphics Engine | AMD Radeon™ RX 9060 XT |
| Model Name | RX9060XT 16G-L/OC |
| Series | Hellhound |
| Stream Processor | 2048 Units |
| Video Memory | 16GB GDDR6 |
| Memory Speed | 20.0 Gbps |
| Memory Interface | 128-bit |
| Engine Clock (OC) | Game Clock: up to 2740MHz, Boost Clock: up to 3310MHz |
| Engine Clock (STD/Silent) | Game Clock: up to 2620MHz, Boost Clock: up to 3230MHz |
| Bus Standard | PCIE 5.0 x16 |
| Standard Display Connectors | 1 x HDMI 2.1b, 2 x DisplayPort 2.1a |
| Feature Support | DirectX® Support: 12, OpenGL: 4.6, AMD Eyefinity Technology: Support, AMD Stream Technology: Support, AMD Smart Access Memory: Support |
| Maximum Resolution | DisplayPort: 7680×4320, HDMI: 7680×4320 |
| Board Dimensions | 310mm x 100mm x 40mm, 330mm x 120mm x 40mm (with bracket) |
| Slot | 2 |
| Minimum System Power Requirement | 550W |
| Extension Power Connector | One 8-pin PCI Express Power connector |
