-60%
Super Flower Zillion DB 550W Bronze Smps
Original price was: ₹9,900.00.₹3,989.00Current price is: ₹3,989.00.
(-60%)- Estimated delivery time 14-30 days
- 18 months warranty at Genuine Warranty Center.
- Whats in the box: charging cable and block
Product details
| Model Name | Zillion DB Bronze 550W |
| Model Number | SF-550Z12DB |
| Wattage | 550W |
| Efficiency (230V EU) | 20%: 85%, 50%: 88%, 100%: 85% (Internal Bronze) |
| Intel Design Compliance | ATX 12V v2.3, EPS 12V v2.92 |
| AC Input / Frequency | 200–240V~ 5A 50–60Hz |
| DC Output Rails | +3.3V, +5V, +12V, -12V, 5VSB |
| Max Output Current | +3.3V: 16A, +5V: 16A, +12V: 42A, -12V: 0.3A, 5VSB: 3A |
| Max Combined Wattage | +3.3V & +5V: 100W, +12V: 504W, -12V: 3.6W, 5VSB: 15W, Total: 550W |
| Cooling Fan Size | 120 mm Sleeve Fan |
| Dimensions (L × W × H) | 140 × 150 × 86 mm |
| Weight | ~1.5 Kg |
| Protection Features | OVP (Over Voltage), SCP (Short Circuit), OPP (Over Power), NLP (No Load Protection) |
| Certifications / Safety | TÜV, CB, CE, RoHS |
| Cable Spec | 20+4 Pin |
| Fixed Cables | 1 × 500 mm |
| CPU Power Cable | 1 × 8Pin & 4+4Pin (600 mm + 150 mm) |
| PCIe Power Cable (SLI) | 1 × (2 × PCI 6+2Pin) – 500 mm + 150 mm |
| Storage Cables | 2 × SATA + 1 × PATA – 450 mm + 150 mm + 150 mm |
| Note | Features, price, and specifications are subject to change without notice. Images are for representation only. |
