Product details
| Resolution | 8 dots/mm (203 DPI) |
| Printing Method | Thermal Transfer & Direct Thermal |
| Max. Print Speed | 254 mm (10”)/second |
| Max. Print Width | 108 mm (4.25″) |
| Max. Print Length | 25,400 mm (1000″) |
| Enclosure | Die-cast based print mechanism, Metal cover with large clear media view window |
| Physical Dimensions | Metric: 248 mm (W) x 274 mm (H) x 436 mm (D) |
| Imperial: 9.76” (W) x 10.79” (H) x 17.17” (D) |
| Weight | 9.2 kg (20.28 lbs) |
| Label Roll Capacity | 203.2 mm (8“) O.D. |
| Ribbon | 450 m long, max. O.D. 81.3 mm, 1“ core (ink coated outside or inside) |
| Ribbon Width | 40 mm ~ 110 mm (1.6” ~ 4.3”) |
| Processor | 32-bit RISC CPU |
| Memory | 128 MB Flash memory, 128 MB SDRAM |
| Interfaces | RS-232, USB 2.0, Internal Ethernet (10/100 Mbps), USB host (for scanner or PC keyboard), GPIO (dealer option), Internal Bluetooth 4.2 (dealer option), Slot-in 802.11 a/b/g/n wireless (dealer option) |
| Power | Input: AC 100-240V, 2.0A, 50-60Hz |
| Output: DC 24V, 3.75A, 90W |
| LED/LCD | 3.5” touch HVGA color LCD, 1 status indicator |
| Operation Switch/Buttons | 6 buttons (Menu, Pause/Feed, Up, Down, Left, Right) |
| Sensors | Gap transmissive sensor (position adjustable), Black mark reflective sensor (position adjustable), Ribbon encoder sensor, Ribbon end sensor, Head open sensor |
| Real Time Clock | Standard |
| Internal Fonts | 8 alpha-numeric bitmap fonts, Monotype Imaging® true type font engine with one CG Triumvirate Bold Condensed scalable font |
| 1D Barcodes | Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, China Post |
| 2D Barcodes | PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| Font & Barcode Rotation | 0, 90, 180, 270 degrees |
| Printer Language | TSPL-EZD (Compatible with EPL, ZPL, ZPL II, DPL) |
| Media Type | Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media Width | 20 ~ 120 mm (0.8” ~ 4.7”) |
| Media Thickness | 0.06 ~ 0.28 mm (2.36 ~ 11 mil) |
| Media Core Diameter | 25.4 mm ~ 76.2 mm (1” ~ 3”) |
| Label Length | 5 ~ 25,400 mm (0.2″ ~ 1000″) |
| Operating Environment | Operation: 5 ~ 40°C, 25 ~ 85% non-condensing |
| Storage: -40 ~ 60°C, 10 ~ 90% non-condensing |
| Safety Regulations | FCC Class A, CE Class A, RCM Class A, cTUVus, CCC, BIS, TÜV, KC, BSMI, EAC, ENERGY STAR® |
| Environmental Compliance | RoHS, WEEE |
| Accessories | Windows labeling software CD, Quick start guide, USB cable, Power cord |
| Limited Warranty | Printer: 2 years |
| Print Head: 25 km (1 million inches) or 12 months (whichever comes first) |
| Platen: 50 km (2 million inches) or 12 months (whichever comes first) |
| Dealer Options | Peel-off kit, 5” OD internal rewinding kit, Regular guillotine cutter (full cut), GPIO, 802.11 a/b/g/n wireless module (for device without slot-in housing), Internal Bluetooth 4.2 |
| User Options | 802.11 a/b/g/n wireless module (for device with slot-in housing), KP-200 Plus keyboard display unit |
