Product details
| Hardware Specifications | |
| Resolution | 600 dpi (24 dots/mm) |
| Print Method | Direct thermal/Thermal transfer |
| Display | Colour LCD touchscreen with buttons |
| Hardwire Connectivity | Ethernet GPIO Parallel port Serial RS-232 USB USB Host |
| Enterprise Printer Management | TSC Console SOTI Connect (license required) |
| Type | Industrial |
| Max. Print Speed | 6 ips (152 mm/s) |
| Max. Print Width | 4.09″ (104 mm) |
| Max. Print Length | 100″ (2,540 mm) |
| RAM | 256 MB SDRAM |
| Flash | 512 MB |
| Expandable Flash | microSD card reader; up to 32 GB |
| Optional Cutter | Regular cutter (full-cut guillotine cutter); Heavy duty cutter (full-cut guillotine cutter); Care label cutter |
Media Specifications
| Internal Label Capacity | 8″ (203.2 mm) OD |
| Max. Media Width | 0.79″ – 4.5″ (20 – 114 mm) |
| Media Type | Continuous; Die-Cut; Black Mark (bottom side or top side black mark); Fan-Fold; Notch; Perforated; Tag; Care Label (Outside Wound) |
| Max. Ribbon Length | 600 Meters |
| Ribbon Width | 1″ – 4.5″ (25.4 – 114.3 mm) |
| Media Core Diameter | 1″ – 3″ (25.4 – 76.2 mm) |
| Min. Label Length | 0.2″ (5 mm) |
| Construction | Die-cast print mechanism and base with a bi-fold metal cover with large clear media view window |
| Programming Languages | TSPL-EZD |
