Programmable 2, 3, 4, 5 or 6 max. (51, 76, 102,127 with max. 152)
Dot Pitch
0.0049” (0.13 mm)
Max. Print Length
39.0” (991 mm)
Min. Print Length
One Dot
Max. Print Width
4.09” (104 mm)
Min. Print Width
One Dot
Ribbon Outside Diameter
2.6”/ 66 mm (300 m); 1.34”/ 34 mm (74 m)
Ribbon Standard Length
984’ (300 meter); 244’ (74 m)
Ribbon Ratio
1:4 media to ribbon (300 m)
1:1 media to ribbon (74 m)
Ribbon Width
1.33”/ 33.8 mm ~ 4.3”/ 109.2 mm
Ribbon Core I.D.
300 m ribbon 1”/ 25.4 mm
74 m ribbon 0.5”/ 12.7 mm
Dimensions
Thermal Transfer • 10.5 in. L x 7.75 in W x 7.5 in. H • 267 mm L x 197 mm W x 191 mm HDirect Thermal • 8.6 in. L x 6.9 in. W x 5.9 in. H • 220 mm L x 176 mm W x 151 mm H
Weight
2.5 lbs./1.1 kg
Operating Temperature
40ºF to 105ºF (5ºC to 41ºC)
Storage Temperature
-40ºF to 140ºF (-40ºC to 60ºC)
Operating Humidity non-condensing
10% to 90%
Storage Humidity non-condensing
5% to 95%
